Technical SpecificationsMaximum Temp. Zone 1 = 1150-C
Temp. Accuracy 1-C
Heating Elements Kanthal - A1 wire, Coil type with end connections
Inner Chamber Ceramic Refractory /Board
Insulation Ceramic Fibre
Construction Split Type (Horizontal)
Body Made of mild steel duly Powder Coated
Max. Tube Size to be accomodated Dia = 70mm/Hot Zone 1 = 225mm/Hot Zone 2 = 450mm/Overall length = 1000mm (approx)
Power Control SSR unit
Temp. Control Microprocessor based PID Digital Set Point Controller individual for each Zone. Dual Display of Set and Actual Temp. with soft touch keys. With Thermocouple break protection & Cold junction compensation.
Sensor Cr/Al for each zone
Safety Over current and Short Circuit Protection. Thermocouple break alarm High Temp. alarm
Power Supply 220 Volts, single phase AC supply.
1.Quartz Tube /Alumina Tube with Couplers (Specify Dia & length)
2.Data logger to store data upto 1 Lakh records,the data can be download in pen drive and viewed on PC in excel sheet.
